Evolution in Raised Access Floor Systems
• Core on Calcium sulphate and fibre density 1.500 kg / 1m3. Top and Low tray
hot deep galvanized steel thk. 0.5 mm double folded lock of fully encapsulated.
• Panel dimensions: 600*600*29 mm / 17,30 kg.
• The dimensional tolerances ratedas per UNI EN 12825 at the highest Class 1.
hot deep galvanized steel thk. 0.5 mm double folded lock of fully encapsulated.
• Panel dimensions: 600*600*29 mm / 17,30 kg.
• The dimensional tolerances ratedas per UNI EN 12825 at the highest Class 1.
© 2009 Joint Pavimenti Bulgaria, Sofia 1408, 105A "Nishava" street, e-mail: info@dvoenpod.net, phone: +359.2.48.30.478, mob: +359.899.99.66.72
• Load baring Performances as per UNI EN 12825 stringerless at FFH 400mm
• Point load at weakest point > 6.25 kN
• Ultimate load with Safety Factor 3 > 13.00 kN
• Working load fixed deflection < 2.5 mm > 6.00 kN
• RATED CLASS AS PER UNI EN 12825 6/3,0/A/1
• Point load at weakest point > 6.25 kN
• Ultimate load with Safety Factor 3 > 13.00 kN
• Working load fixed deflection < 2.5 mm > 6.00 kN
• RATED CLASS AS PER UNI EN 12825 6/3,0/A/1
• Fire Performance
• Fire reaction EN 13501-1: Class 0, A2fl-S1
• Fire resistance EN 13501-2: R.E.I. 60, R.E.90
• Fire rate as per PSAMOB: Index i1, Class 1,Rating class 0
• Fire reaction EN 13501-1: Class 0, A2fl-S1
• Fire resistance EN 13501-2: R.E.I. 60, R.E.90
• Fire rate as per PSAMOB: Index i1, Class 1,Rating class 0
• Noise Attenuation EN 20140-9 & EN 20140 - 6:
• Air bone noise as per ISO 717 - 1 Dn1f1w: > 44 dB
• Impact noise as per ISO 717 - 2 Ln1w: < 67 dB
• Air bone noise as per ISO 717 - 1 Dn1f1w: > 44 dB
• Impact noise as per ISO 717 - 2 Ln1w: < 67 dB
P4TTH - Heavy Grade
• Proposed for office and commercial use.
• Used as working platform during construction.
• Water and reagents poof.
• 25 YEARS WARRANTY
• Used as working platform during construction.
• Water and reagents poof.
• 25 YEARS WARRANTY
